Hikvision DS-PM1-O1H-WB Wall Switch Relay Module

Category Feature Specification Software Features Scenario Setting By Alarm, By Operation, By Fault, By Schedule, By Manual Learning Button 1, For register Hardware Features Serial Port 1, for debug Electrical Characteristics Power Supply AC 100v – 240v, 50/60 HZ Operation Humidity 10％~90％ Operation Temperature ﹣10℃~+55℃ Wireless Transmission RF Frequency 433MHz RF Method Two-way communication RF Modulation 2GFSK RF Distance 800m Wireless Security AES-128 Display LEDs Status 3, Register/Signal (Green/Red), Power (Green), Relay Status (Blue) Relay Output 1, NO/NC (AC 100~240v, Max 13A) General Installation Method Wall Mounting or Inside 86 box Dimension (WxHxD) 38x25x18mm Shell Material Plastic Color White Weight 31.5g
